No need to swing that leg to mount this ebike, just step-through and have fun! This 28mph Class III e-bike
maximizes your outdoor activities and keeps you going on. It's like
powering up your legs to make hills a thing of the past. Equipped with
large comfortable tires, the Pace gives you the ultimate balance in
comfort and power. With a relaxed, upright riding position and 5-levels
of pedal-assist, this ride will keep the smile on your face all day
long.
Pace
500 ships as a Class III ebike, with up to 28 MPH on pedal assist and
20 MPH on throttle. If you are riding on private property or in an area
without ebike speed restrictions, the speed limit can be modified in the
settings, and Pace 500's powerful motor can go up to about 32 MPH on
pedal assist. Pace 500 will also operate with the throttle unplugged and
removed, should you want to ride in an area where throttles are not
allowed.
Aventon ebikes are built to the IPX4 water-resistant standard. IPX4
means that your bike is resistant to water splashes from any direction.
This means it’s OK to ride or park your ebike in the rain. It won’t be
harmed by spray from a wet road or raindrops. Your ebike is not intended
to be submerged or subjected to a pressurized spray. Don’t use a
pressure washer or sprayer to clean your ebike.
ELECTRONICS
Motor
750W (Peak), 48V Brushless Rear Hub Motor
500W (Sustained)
Speed
Max 28 Miles on pedal assist or throttle
Pedal Assist
5 Levels
Battery
Lithium-ion 48V, 11.6Ah (556.8Wh) with Samsung Cells
Charger
48V 3 Amp Fast Charger, 3-4 Hour Charging
Display
LCD Smart Easy Read Display with Backlight
Sensors
Cadence Sensor
Range
25-40 Miles Estimated
FRAME AND ACCESSORIES
Frame
6061 Double-Butted Aluminum Alloy
Fork
6061 Aluminum Alloy, tapered
Weight
49lbs
Weight Limit
Maximum Rider Weight: 250lbs
Cargo Capacity: 50lbs
Pedals
9/16" Alloy Platform
DRIVETRAIN & BRAKES
Bottom Bracket
Square Tapered, Sealed
Cassette
Shimano Altus 11-32 Cassette, 8 Speed
Chain
KMC Z Series, 8 Speed
Crankset
170mm w/ 42 T
Shift Levers
Shimano 8 Speed Altus
Rear Deraileur
Shimano Altus 8 Speed
Brakes
Tektro HD-T285 Hydraulic Disc Brakes w/ 180mm Rotors
WHEELS & TIRES
Rim
Double Wall Aluminum 36h Front & Rear
Hub
Joytech 36H Disc Nutted Front and Rear
Spokes
Black Stainless
Tires
27.5" x 2.2" Kenda Kwick Seven Sport, Ebike
Tubes
Butyl Rubber, Schrader Valve
CONTACT POINTS
Saddle
Aventon Velo Comfort, Steel Rails, 245mm wide
Seat Clamp
Quick Release
Grips
Ergonomic Comfort
Seatpost
Forged Alloy, 30.4mm, 2-Bolt Clamp
Handlebars
Aluminum 31.8 15 Degree Sweptback
Stem
Threadless, Adjustable 31.8mm
Headset
VP Sealed Bearing Headset
