Speeds: 1 x 10
Weight: 12 kg (26.5 lb)
Gear Inches: 28" - 90" (2.20 - 7.19 m)
Folding Size: 33 × 81 × 51 cm (13 × 31.9 × 20.1 in)
Folding Time: 30 seconds
Frame Sizes: One size
Distance: Seatpost to Handlebar: 63 - 67.5 cm (24.8 - 26.6 in)
Suggested Rider Height: 147 - 195 cm (57.9 - 76.8 in)
Max Gross Vehicle Weight: 120 kg (264.6 lb)
Max Load Weight: 105 kg (231.5 lb)
Max Rider Weight: 105 kg (231.5 lb)
Frame
Frame:
Tern BYB, 6061-AL, Aluminum, TriFold patented technology, EFBE tested: ISO 4210
Fork:
Tern Tarsus, 6061-AL, hydroformed
Cockpit
Handlepost:
Tern Physis RF, 3D forged, 5 patented technologies
Stem:
Tern Andros (G2), adjustable, forged construction, patented technology
Headset:
Tern Flux by FSA, cartridge bearings, Physis integrated
Handlebar:
Flat bar, 6061-AL, Andros adapted
Grips/Bar
Tape:
Ergon GP10
Saddle:
Tern Porter+ by Velo, patented GripPad design, PrimeGel padding
Seatpost:
Tern Telescope, 34.9/30.9 mm, 2014-AL
Seatpost Clamp:
Tern Collar
Brakes
Front Brake:
Kinetix SpeedStop V-brakes, stainless hardware
Rear Brake:
Kinetix SpeedStop V-brakes, stainless hardware
Brake Levers:
Shimano
Brake Cable & Housing:
Jagwire, anti-compression housing, Slick Lube liner
Wheels
Front Wheel:
Kinetix Pro, Paired Spoke technology, 16H
Rear Wheel:
Kinetix Pro, Paired Spoke technology, 20H
Tires:
Schwalbe Kojak, Performance Line, 35-406, puncture protection
Transmission
Shifter(s):
Shimano Deore, 1 x 10 spd
Front Derailleur:
n/a
Rear Derailleur:
Shimano Deore Shadow+
Crankset:
FSA Vero, Built for Tern, 53T
Cassette/
Freewheel:
11-36T, 10 spd
Bottom Bracket:
FSA, Cartridge, sealed bearings
Chain:
KMC X10
Pedals:
MKS EZY
Shifter
Cable & Housing:
Jagwire LEX-SL, slick treatment, alloy ferrules
