Specifications
SIZE GUIDE
Bike Size
Regular / Large
User Height Range
R：5'2''~5'11'' L：5'9''~6'7''
（With Suspension Seatpost）
R：4'11''~5'9'' L：5'6''~6'4''
（Without Suspension Seatpost）
FRAMESET
Frame
Triple-Butted Aluminum Alloy
Fork
Air suspension 80mm Travel with Lock-out
ELECTRONICS
Motor
48V, 750W, 1100W(Peak Power), 75Nm
Battery
48V, 15.2Ah(730Wh), IPX7, Certificated by UL 2271
Cell
Samsung/LG 21700 cell, Certificated by UL2580
Charger
48V, 3A Fast Charger
Sensor
Torque and Cadence Sensor
Display
3.5" Full color, High brightness, Bluetooth, NFC, Adjustable Angle
USB Port
USB Type-C phone Charge
Throttle
Trigger-control, Removable
Pedal Assist
5 Riding Modes /Ride Tuning
Walk Mode
2.9MPH/ Walk & Hold
Front Light
500LM High-output Integrated LED, Adjustable Angle
Rear Light
Braking Indicator, Turn Signal, Rear Light Steady/Flash, Integrated with Rear Rack
Water Resistant
IPX6
App
App OTA
Anti-theft
Apple Find My & Google's Find Hub，NFC Card Unlock
SPEED & RANGE
Max Speed (Default）
20MPH
Max Speed Adjustable Range
12~28MPH
Ebike Class
1/2/3
Pedal Assist Range
80 Miles
Throttle Range
65 Miles
DRIVETRAIN
Chainrings
46T Narrow-Wide Chainring
Crankset
Aluminum Alloy, 170mm
Freewheel
8-speed,11-40T
Rear Derailleur
SHIMANO 8-speed
Shift Lever
SHIMANO 8-speed
Chain
KMC 8-speed
BRAKE
Brake
Tektro Hydraulic Disc Brake
Rotors
180mm Front/180mm Rear
Brake Levers
Aluminum Alloy, with Power Cutoff
WHEEL
Rims
Aluminum Alloy
Front Hub
NOVATEC Aluminum Alloy, 15x110mm Thru-axle
Tire
KENDA 27.5x2.4" eBike Puncture Resistant Tires
COCKPIT
Handlebar
Aluminum Alloy, Ф31.8mm, 680mm(R)/700mm(L)
Grips
Durable Ergonomic Grips, Lockable
Stem
Adjustable, Aluminum Alloy, ф31.8mm, 60mm Length
Saddle
VELOTRIC Comfort Ergonomic Seat
Seatpost
Aluminum Alloy, Ф30.9mm, Suspension
Clamp
Aluminum Alloy, Quick Release
SUPPORTS
Fenders
Aluminum Alloy, Front and Rear Full Coverage
Rear Rack
MIK HD Compatible Alloy
Pedals
Plastic
Kickstand
Aluminum Alloy, Included, Rear Mount
WEIGHT & LOAD
Bike Weight
61 lbs
Rear Rack Load Capacity
66 lbs
Max Bike Load Capacity
440 lbs
CERTIFICATION
UL Certification
UL2849 & UL2271
ISO Standard
ISO 4210
Geometry
Height
5'2"~5'11"
Reach
373mm
Handlebar Height
1110mm
Wheelbase
1113mm
Stand-Over Height
400mm
Min Saddle Height
829mm
Max Saddle Height
985mm
Total Length
1818mm
